Plasma Cutting Machine
Trusted Name for Complete Welding Applications
CUT Series MOFSET Inverter Air Plasma Cutter
Product Description - CUT-40, CUT-60
- Advanced inverter with pulse width technology-Light Weight & Compact Design
- High frequency transformer with soft magnetic ferrite-High efficiency & Energy savings
- Arc striking even in non-contact mode
- Adopting passive power factor correction- Energy savings
- Protection against Over Heat. Over Voltage & Surge in input supply- safety in operation
- Unique rugged design- Reliability, Durability & Ease of maintenance
Main Technical Parameters
| CUT-40 | CUT-60 | |
|---|---|---|
| Input Power Voltage: | AC 230V +/- 10% | AC 230v +/- 10% |
| Frequency(Hz): | 50/60 | 50/60 |
| Rated Input current(A): | 30 | 44 |
| Rated Output voltage(V): | 96 | 102 |
| No Load Voltage : | 240 | 240 |
| Current Adjusting Range | 20-40 | 20-60 |
| Duty Cycle(%): | 60% | 60% |
| Effiency(%): | 80% | 80% |
| Power factor | 0.73 | 0.73 |
| Insulation class | F | F |
| Case protection degree | IP21 | IP21 |
| Overall dimension: | 371 x 153 x 232 | 371 x 153 x 232 |
| Weight(Kg): | 7 | 8 |
CUT Series IGBT Inverter Air Plasma Cutter
Product Description
- Latest design with IGBT Inverter technology - Light weight & compact design
- Facility for setting exact current digitally-Ease of operation
- High frequency & high pressure arc striking - 100% ARC striking ensured
- Advanced air flow control - Fine control of air flow hence longer life of compressor
- Protection against over heat, no voltage, over voltage & surge in current - safety in operation
- Unique rugged design - Reliability, Durability & Ease of Maintenance
Main Technical Parameters
| Model | CUT - 80IJ | CUT - 100IJ | CUT - 160IJ2 |
|---|---|---|---|
| Input Power Voltage(V) : | AC415V +/- 10% | AC415V +/- 10% | AC415V +/- 10% |
| Frequancy(Hz) : | 3-50Hz/60Hz | 3-50Hz/60Hz | 3-50Hz/60Hz |
| Rated Output Capacity (KVA) : | 12 KVA | 25.5 KVA | 28 KVA |
| Rated Input Current(A) : | 20.2 | 32.3 | 42 |
| No Load Voltage(V) : | 290V | 350V | 400V |
| Current Adjustig Range(A) : | 38-80A | 30-100A | 30-160A |
| Duty Cycle(%) : | 60% | 60% | 60% |
| Working Gas Pressure(MPA) : | 0.4-0.6 | 0.5-0.7 | 0.5-0.8 |
| Case Protection Degree : | IP21 | IP21 | IP21 |
| Arc Starting : | Non Touch | Non Touch | Non Touch |
| Max Cutting Thickness : | < 15mm | < 25mm | < 50mm |
| Overall Dimension(mm) : | 530 x 260 x 470 | 576 X 297 X 557 | 576 x 297 x 557 |
| Weight(Kg) : | 21 | 35 | 46 |
